YAC 2065

GaN Wall Charger 65W

  1. Compact size
  2. Super Fast Charging
  3. Innovative GaN technology

Innovative GaN technology

The revolutionary Gallium Nitride technology has enabled the YAC 2065 charger to store power of up to 65W in an exceptionally small body.
Další
Zpět
Innovative GaN technology

It can handle mobile phones, tablets and laptops

Rich connector equipment that can handle laptops, phones and tablets. All this with the support of state-of-the-art charging protocols for wide compatibility.
Další
Zpět
It can handle mobile phones, tablets and laptops

It also charges the laptop

The top performance hidden in the body of a standard mobile phone charger is rich enough to charge and power laptops.
Další
Zpět
It also charges the laptop

Compact size

Up to 30% smaller dimensions compared to existing technologies. A compact body means one thing. YAC 2065 is made for frequent travelling.
Další
Zpět
Compact size

I can even cope with laptops

Phone? I can do it. Tablet? I can do it. Laptop? I can do it too. The power of up to 65W can easily cope with laptops, for which the manufacturer may have packed a large unsightly brick called a charger. With me, however, the need to carry this load in the backpack is completely eliminated. In one small body, you will find a solution for charging your mobile phone and laptop, still at high performance. Specifically, when both USB-C ports are connected, this is 1x 45W and 1x 18W.

Small, yet powerful!

Travelling? Me too. And all the time. From one socket into the backpack, then into another socket. I have really travelled every corner of quite a few households or offices. Quite right, too. Thanks to my compact dimensions, I will not complicate your life in any way. You will always find a place for me. However, my smallness is only in dimensions. My power is giant. I owe this to the new innovative GaN (Gallium Nitride) technology, which allows to reduce the charger body size by up to 30% and still maintain the high performance of my larger colleagues.

Smart and for everyone

In addition to being powerful and compact, I am mainly smart. My body incorporates a smart chip that communicates with the device being charged, and it always selects optimal output power so that it does not damage the connected electronics while charging it as quickly as possible. There are also two USB-C ports and one USB-A connector on my body that supports QuickCharge technology. When it comes to supporting charging protocols, you don't have to worry. It is worth mentioning QuickCharge, Power Delivery or Apple 2.4 A, to name a few.
YAC 2065

Specifications:

Model identifier YAC 2065
Input voltage AC 100–240 V
Input frequency 50/60 Hz
Output voltage DC 3,3–20,0 V
Output current 3,0–5,0 A
Output power 65,0 W
Average active efficiency sheet
Efficiency at low load (10 %) sheet
No-load power consumption sheet
Dimension 72,5 × 36,5 × 31,5 mm
Weight 122 g

Output:
USB A 4,5 V 5,0 A / 5,0 V 4,5 A / 9,0 V 3,0 A / 12,0 V 3,0 A / 20,0 V 3,0 A
USB C1 3,3 V – 20,0 V 3,0 A / 5,0 V 3,0 A / 9,0 V 3,0 A / 12,0 V 3,0 A / 15,0 V 3,0 A / 20,0 V 3,25 A
USB C2 3,3 V – 20,0 V 3,0 A / 5,0 V 3,0 A / 9,0 V 3,0 A / 12,0 V 3,0 A / 15,0 V 3,0 A / 20,0 V 3,25 A

Output power simultaneously:
USB-C1 + USB-C2 USB-C1 + USB-C2: 45,0W + 18,0W (Total 63,0W Max)
USB-C1 + USB-A USB-C1 + USB-A: 45,0W + 18,0W (Total 63,0W Max)
USB-C2 + USB-A USB-C2 + USB-A: total 5,0V 4.8A MAX
USB-C1 + USB-C2 + USB-A 45,0W + 15,0W (Total 60,0W Max)
